Linear Lubricant Automatic Bottling Plant Frequency Speed Control

    Buy cheap Linear Lubricant Automatic Bottling Plant Frequency Speed Control from wholesalers

    Buy cheap Linear Lubricant Automatic Bottling Plant Frequency Speed Control from wholesalers
    • Buy cheap Linear Lubricant Automatic Bottling Plant Frequency Speed Control from wholesalers

    Linear Lubricant Automatic Bottling Plant Frequency Speed Control

    Ask Lasest Price
    Brand Name : NPACK
    Model Number : NP-VF
    Certification : CE ISO
    Supply Ability : 10 Set/Sets per Month Linear cheap filling lubricant machine
    Price : $5,000.00 - $18,000.00 / Sets
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Linear Lubricant Automatic Bottling Plant Frequency Speed Control

    ►Linear Cheap Filling Lubricant Machine

    The machine was design and manufactured by Shanghai Npack Automation equipment co.,ltd, especial for liquid from thin viscous to high density liquid, such as water, oil, lotion, cream, Jam, sauce, honey, ketchup and so on. It is mostly used in the industry of chemicals, foodstuff and pharmaceuticals.

    ► Advantages

    1. filling nozzles from 2 -16 nozzles for option
    2. anti- drops, equipped with shut off filling nozzles
    3. when filling, the filling nozzles will insert into the bottom of the bottles
    4. Filling volume can be automatically adjusting by touch screen , meanwhile customer also can choose adjust by rotary handle for economy investment.
    5. Frequency speed control, and no bottle no filling
    6. Top liquid hopper application, and automatically warning on lack of liquid , and automatic

    ► Technical parameters

    • Model:NP-V F
    • Filling Nozzles:2-12 nozzles, or customized
    • Applied bottle range:30-100ml, 100-1000ml, 900ml-5000ml
    • Material density:0.6-1.5
    • Tolerance of filling quantity (accuracy):±£1%
    • Filling speed:800-4200 bottles/hour , 30b/min per 4 filling nozzles 1L
    • Power:2KW
    • Voltage:220V,380V ,50HZ /60HZ
    • Air Pressure:0.6Map
    • Air Consumption:1.2-1.4m³/min
    • Weight:500KG
    • Dimension:2300*1200*1760MM
    • Control:touch screen, PLC control

    ► Components List

    No.DescriptionsBRANDITEMRemark
    1Servo MotorPanasonic1.5KWJapan
    2ReducerFenghuaATF1205-15Taiwan
    3Conveyor MotorZhenYuYZ2-8024China
    4Servo DriversPanasonicLXM 23DU15M3XJapan
    5PLCSchneiderTM218LDALCODR4PHNFrance
    6Touch ScreenSchneiderHMZGXU3500France
    7Frequency ConverterSchneiderATV12H075M2France
    8Photo electricity of Inspect bottleOptexBRF-NJapan
    9Pneumatic ElementAirtacTaiwan
    10Rotary ValveF07/F05No Need for Oil
    11Pneumatic actuatorF07/F05No Need for Oil
    12Low-Voltage ApparatusSchneiderFRANCE
    13Proximity SwitchROKOSC1204-NTaiwan
    14BearingChina
    15Lead ScrewTBITaiwan
    16Butterfly ValveCHZNAChina

    Company Introduction
    Linear Lubricant Automatic Bottling Plant Frequency Speed ControlLinear Lubricant Automatic Bottling Plant Frequency Speed Control

    NPACK with more than 10 years experiences in this industry and large technical in our factory.There are 12 senior engineers.And,we have export our machine to more than 60 countries,such as Vietnam,Thailand, Malaysia, American,Indonesia, Nigeria,Egypt,and so on. There are more than 1,000 foreign customers.

    it is a professional manufacturer and supplier of various types of liquid, powder, paste, granular packing machines since 2008.And in 2012, NPACK stepped into a new stage, and supply one stop packaging solution. And turn key projects for customers, now NPACK is one of the top brand in packaging machineries, and get a good Reputation in the fields of Chemicals &cosmetics, Pharmaceuticals and Food industry. In 2014, NPACK invested a new Plant for printing self adhesive labels( stickers labels in rolls) SHANGHAI RENYI PRINTING TECHNOLOGY CO.,LTD


    Our Factory

    Linear Lubricant Automatic Bottling Plant Frequency Speed Control

    Our Advantages

    1.more than 10 years experiences in this industry and large technical in our factory.

    2.have export our machine to more than 60 countries.

    3.There are more than 1,000 foreign customers.

    4.There are 12 senior engineers in our factory.

    5.The material of our machine is 100% 314/316 stainless steel.


    Our Services

    Training:

    1. We offer machines training system, the customer can choose training in our factory or in customer workshop. The normal training days are 3-5 days.
    2. We offer operation manual to customer.
    3. We offer training video and machine operation video to customer.
    4. We offer remote control service, if customer do not know how to operate and use the machine.

    Installation:

    We will dispatch engineers to carry out installation and debugging of the equipment in buyer's place if requested. The cost for International double ways air tickets, accommodations, food and transportations, medical shall be paid by Buyer for the engineers. Buyer shall fully cooperate with Supplier's engineer and make all the installation condition ready to work.

    Warranty:

    The Manufacturer shall guarantee the goods are made of Manufacturer’s best materials. The sold machine will be guarantee in one year, in the guarantee year, any spare parts broken due to supplier’s quality issue, the spare parts will be supplied free for customer, customer need to pay the freight cost if the parcel weight more than 500gram.

    brand

    FAQ
    Q: Are you factory or trading company?
    A: We are factory focus on designing, manufacturing, assembling, installing and debugging various types of filling machines, capping machines and labeling machines since 2008.

    Q: Can you send a video showing how your machine works ?
    A: Certainly, we have made all our machine's video.

    Q: Do you make test before shipment?
    A: We always test machine fully and make sure it works smoothly before shipment.

    Q: What is the term of payment and trade terms?
    A: We accept T/T, Western Union, MoneyGram, Alibaba Trade Assurance payments.
    Trade Term : EXW,FOB,CIF,CNF.

    Q: What’s the MOQ and warranty?
    A: There is no MOQ , welcome to order, we promise 24 month warranty .

    Q: What kind of package for shipping?
    A: Use the basic stretch film wrap around the whole machine,and packed with exported wooden case , also can be according to your requirements.
